| Featuring 5,200 lumens high-brightness capability, along with Full HD, WUXGA, 16:6 wide screen, support for 4K input and detail enhancement technology, it gives users brighter, more vivid displays of up to 500”. Providing more premium features than you would typically expect to find in this display class, the EB-L520U delivers edge-blending and geometric correction to achieve one seamless large-format display. And for multimedia content, you can playback content without any lagging, and create playlists and set schedules directly from USB memory, all thanks to H.264 advanced video coding and the Epson Content Manager. Flexibility is another hallmark of this display solution - a split-screen function allows two or four images from different sources to be combined in one large display wired or optional wireless1 with support for Miracast1 makes connectivity simple and straightforward and HDBaseT content can be shared and distributed without compromising on quality. Thanks to the renowned market leading2 reliability of Epson laser displays, this fit and forget solution eliminates the need for regular maintenance. And for added confidence the EB-L520U comes with a standard 3-year warranty to provide lasting peace of mind.
Proiettore
Compatibilità dimensione schermo*
1270 - 12700 mm (50 - 500")
Rapporto di contrasto (dinamico)
5000000:1
Luminosità proiettore*
5200 ANSI lumen
Tecnologia di proiezione*
3LCD
Risoluzione nativa del proiettore*
WUXGA (1920x1200)
Rapporto di contrasto*
2500000:1
Formato schermo (aspect ratio)*
16:10
Numero di colori
1,07 miliardi di colori
illuminazione del proiettore (economic mode)
3640 ANSI lumen
Intervallo di scansione verticale
192 - 240 Hz
Correzione Keystone, orizzontale
±30°
Correzione Keystone, verticale
±30°
Dimensione della matrice
1,7 cm (0.67")
Sorgente luminosa
Tipo di sorgente luminosa*
Laser
Durata della sorgente luminosa*
20000 h
Durata della sorgente luminosa (modalità risparmio)
30000 h
Sistema di lente
Lunghezza focale
20 - 31.8 mm
Range di apertura (F-F)
1,5 - 1,7
Rapporto di proiezione
1.35 - 2.20:1
Video
Formato video analogico*
Non supportato
Elaborazione video
10 bit
Modalità colore video
Cinema, Modalità di simulazione DICOM, Dinamico, Presentazione, sRGB
Connettività
Quantità di porte di tipo-B USB 2.0
1
Tipo interfaccia seriale*
RS-232C
Quantità porte VGA (D-Sub)*
3
Collegamento in rete
Collegamento ethernet LAN*
Sì
Standard Wi-Fi
802.11a, Wi-Fi 4 (802.11n)
Archiviazione
Lettore di schede integrato*
No
Caratteristiche
Emissione acustica (modalità economica)
23 dB
Emissione acustica*
31 dB
Paese di origine
Filippine
Multimediale
Altoparlanti incorporati*
Sì
Potenza in uscita (RMS)
10 W
Numero di altoparlanti incorporati
1
Design
Posizionamento di mercato*
Presentazione
Tipo di prodotto*
Proiettore a raggio standard
Colore del prodotto*
Bianco
Installazione
Soffitto, Desktop, Pavimento, Parete
Tipologia slot blocco cavo
Kensington
Gestione energetica
Consumi (modalità stand-by)*
0,3 W
Consumo energia (modalità economica)
223 W
Tensione di ingresso AC
100 - 240 V
Frequenza di ingresso AC
50 - 60 Hz
Software
Supporto software
via: AMX, Crestron (Network), Control4, Crestron Integrated Partner, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol
Condizioni ambientali
Intervallo di temperatura
-10 - 60 °C
Range di umidità di funzionamento
20 - 80%
Dimensioni e peso
Profondità imballo
530 mm
Peso dell'imballo
10,4 kg
Contenuto dell'imballo
Telecomando portatile*
Sì
Software forniti
EasyMP Multi PC Projection
Dettagli tecnici
altre funzioni
21:9 aspect ratio support, A/V mute, Arc Correction, Built-in speaker, CEC compatible, Easy OSD pre-setting, Edge Blending, Long light source life, PC Free, Quick Corner, Screen share, Source function, Ultra-wide display (16:6), iProjection App
Funzione display USB
3 in 1: Image / Mouse / Sound
Certificati di sostenibilità
TCO
Supporto per app per cellulare
Sì
Dati logistici
Quantità per pallett
14 pz
Quantità per pallet (UK)
14 pz
Codice del Sistema Armonizzato (SA)
85286200
Altre caratteristiche
Tipo di opzioni
Air filter, Ceiling mount, Document camera, External Speaker, HDBaseT Transmitter, Safety wire set, Suspension adapter, WP System - ELPWP10, Wireless LAN unit, Wireless transmitter - ELPWT01
Interfaccia
RS-232C, VGA in (2x), VGA out, HDMI in (2x), HDBaseT, Miracast (optional), Jack plug out, Jack plug in (2x), USB 2.0-A, USB 2.0, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac (optional)
Pannello di controllo
0.67 inch with C2 Fine
Caratteristiche sicurezza
Kensington lock, Padlock, Security cable hole, Wireless LAN unit lock
