Near silent operationThe GS1900 Series includes both fan-less and built-in smart fan models. The smart fan is designed to automatically adjust speed based on device temperature. You can barely hear the sound while the switch is operating. It is ideal for your office environment.
Intelligent PoE+ powers more devicesPoE models (8HP/10HP/24EP/24HPv2/48HPv2) come with default PoE consumption mode which delivers only the actual power required by your networked devices, reserves the rest and optimizes its power budget. That means a single switch can power more APs, IP cameras and VoIP phones, ensuring a better ROI for your business. All of them support the IEEE 802.3at providing a maximum of 30W per port.
Speedy Gigabit performance—built for SMBsThe GS1900 is a series of switches with full non-blocking bandwidth of up to 1 Gbps per port. An ideal upgrade from an unmanaged switch, it’s a great choice for SMBs that want to enjoy high-speed business network applications at full wired non-blocking speed.
Easy and intuitive managementThe Smart Managed GS1900 Series switch feature with web-based interface to manage advanced functions such as VLAN, QoS, IGMP Snooping, Link Aggregation (LAG), IPv6 and DoS prevention easily. Also, the user-friendly wizard helps to walk through setup, configuration and even advanced settings quickly.
Caratteristiche di gestione
Tipo interruttore*
Gestito
Livello del commutatore
L2
Supporto qualità del servizio (QoS)
Sì
Registro evento di sistema
Sì
Supporto MIB
RFC 1213 MIB II, RFC 2819 RMON (group 1, 2, 3, 9), RFC 1215, RFC 1493
Connettività
Quantità di porte RJ-45*
24
Tipo di porte RJ-45*
Gigabit Ethernet (10/100/1000)
Quantità di slot per modulo SFP
2
Connettore di alimentazione
Jack di ingresso AC
Collegamento in rete
Standard di rete*
IEEE 802.1D, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Supporto controllo flusso
Sì
Apertura albero di protocollo
Sì
Velocità trasferimento Ethernet LAN
10,100,1000 Mbit/s
Auto-apprendimento dell'indirizzo MAC supportato
Sì
Caratteristiche della LAN virtuale
Tagged VLAN, VLAN Identifier ( VLAN ID), Voice VLAN
Trasmissione dati
Capacità di commutazione*
52 Gbit/s
Dimensioni tavola MAC*
8000 voci
Buffer di memoria di pacchetto
0,525 MB
Sicurezza
Caratteristiche DHCP
DHCP client
Funzione IGMP snooping
Sì
Algoritmi di sicurezza supportati
802.1x RADIUS
Porta di sicurezza statica
Sì
Protezione della password
Sì
tipo di autenticazione
RADIUS, TACACS+
Prestazione
Tempo medio tra guasti (MTBF)
432,673 h
Gestione energetica
Fonte di alimentazione inclusa*
Sì
Tensione di ingresso AC
100 - 240 V
Frequenza di ingresso AC
50 - 60 Hz
Consumo energetico (max)
16 W
Power over Ethernet (PoE)
Supporto Power over Ethernet (PoE)*
No
Condizioni ambientali
Intervallo temperatura di funzionamento
0 - 50 °C
Intervallo di temperatura
-40 - 70 °C
Range di umidità di funzionamento
10 - 95%
Dissipazione del calore
55 BTU/h
Contenuto dell'imballo
Kit di montaggio per rack
Sì
Dati su imballaggio
Profondità imballo
217 mm
Peso dell'imballo
2,85 kg
Certificati di sicurezza
Certificazione
EMC■ CE, FCC, C-Tick, Class A(GS1900-24/24EP/24HPv2/48/48HPv2)■ CE, FCC, C-Tick, Class B(GS1900-8/8HP/10HP/16/24E)■ BSMI CNS13438• Safety■ LVD EN60950-1■ BSMI CNS14336-1■ CB IEC60950-1(GS1900-8HP/10HP/16/24E/24)• RoHS compliant
Dati logistici
Codice del Sistema Armonizzato (SA)
85176990
